Home » Machinery & Accessories » Dust Extraction » Charnwood DC50 High Filtration Vacuum Extractor, 50L Capacity
This fine filter vacuum extractor is ideal for small workshops using bench top machinery and powertools. Because these machines generate a high speed of air through the hose they are more suitable for reducing down to a smaller diameter hose for use with portable power tools.
At the heart of the extractor is a 2 stage filter which cleans particles out of the air down to 0.5 micron. Fine enough for every machine in the workshop including sanders. The compact size and light weight, makes it particularly appealing for smaller workshops, where space is a premium, and it can be kept underneath a bench. A quick action clamp releases the lid of the drum to empty it out.
These extractors are a great alternative to a standard household vacuum because they do not get blocked and have a larger capacity, so need emptying less often.
Supplied with 2m length of 100mm internal diameter hose, 2 hose clamps, 3 replacement filter bags, 2m cable and plug.
Please Note : Hose is Left Hand thread so for quick connector use 100QCL
Specification | Value |
---|---|
Motor (carbon brush) | 1100w (1.5hp), 240v |
Flowrate | 3.05m3/min (53 Litres per second) |
Inlet Diameter | 93mm (For 100mm Hose) |
Drum Capacity | 50 Litres |
Dimensions (WxDxH) | 390mm x 450mm x 670mm |
Weight | 10kg |
Max. Runtime Without Rest | 30 Minutes |
Assembly Time Required | 5 Minutes |
Rating | Hobby |
Product Guarantee | 5 Years |
