Charnwood Universal Wheel Base

Product Code:W522
Barcode: 5060486040193
(1 customer review)

£79.00 (£65.83 Excl. VAT)

Out of stock | Expected Back In Stock: 15 May 2023

Join the waitlist to be emailed when this product becomes available

Product Description

Universal Wheel Kit with wide pedal design and heavy weight capacity.

Constantly having to push one machine to the back of the workshop to make space to bring another one forward?

Convert your machines into portable units by adding this highly adaptable wheel base. There are two fixed wheels and two steering wheels allowing excellent manoeuvring across a relatively flat floor surface. Step on the two foot plates to lower the wheels for moving the machine, then raise the two foot plates to lower the base back onto the adjustable rubber feet.
The base can be assembled either as a square shape or a rectangle shape to suit the footprint of the machine being mounted.
It can be used with a huge variety of machines including Planer Thicknessers, Table Saws, Bandsaws, Spindle Moulders and Lathes.

Charnwood W522 Specification

Minimum square size 340mm x 340mm
Maximum square size 930mm x 930mm
Maximum rectangle size 520mm x 1340mm
Maximum weight load 295kg
Assembly Time Required 20 Minutes
Rating Light trade
Product Guarantee 1 Year

Compatible products from the Charnwood range include;

W014 Router Table
W020 Router Table
W570 Thicknesser on the optional floor stand
W575 Thicknesser on the optional floor stand
W583 10″ x 7″ Planer Thicknesser
W590 12″ Planer Thicknesser
W614 10″ Table Saw
W616 10″ Table Saw
W618 8″ Table Saw
W619 8″ Table Saw
W629 10″ Table Saw
W650 10″ Table Saw
W812 Wood Lathe
W813 Wood Lathe
W326 Morticer
W335 Morticer on optional floor stand
W340 1″ Morticer on optional floor stand
W350 1″ Morticer
B250 10″ Bandsaw
W720 12″ Bandsaw
W721 12″ Bandsaw
B300 12″ Bandsaw
W730 14″ Bandsaw
B350 14″ Bandsaw
W030 Spindle Moulder
W040 Spindle Moulder

1 review for Charnwood Universal Wheel Base

  1. Ray Floyd

    Bought this unit because I needed to be able to move the Charnwood W813 around the workroom. It arrived two days after the order was placed and I set about putting it together, at this point I must admit this pile of meccano in front of me didn’t look up to much and the assembly instructions looked a little vague, however on following the instructions to the letter an hour later I had completed the build. The next step was to put the lathe onto the base this was easier than I thought although it took two of us (got to give my darling wife credit here, thanks love) once the lathe was mounted it rolled around the floor very easily and the base is very solid when in the down position. Just one point though, the instructions tell you to set the standing feet at the riser end to the level of the captive wheels before you finish the build, believe me it’s easier to set these feet after you have mounted the lathe as your floor may not be level and the trolley will move when you start to use the lathe. Other than that a brilliant piece of kit and worth every penny of your money, very robust when the lathe is mounted and a credit to Charnwood. I can now move my lathe for cleaning and servicing very easily well done Charnwood a great piece of kit.
