Charnwood 1hp Portable Dust Extractor

Product Code:W696
Barcode: 5060281690074
(1 customer review)

£269.00 (£224.17 Excl. VAT)

Out of stock | Expected Back In Stock: 24 February 2023

Join the waitlist to be emailed when this product becomes available

Product Description

The best buy in our Hobby range of wood dust and chip extractors, this amazingly low priced unit brings affordable dust control to the woodworking enthusiast.

It is a portable floor standing unit intended for the one-man workshop and can be connected to any bench top machine or floor standing machine such as bandsaws, planer thicknessers, table saws. The inclusion of the floor sweeping attachment is a great aid when sweeping under the benches and floor stands with a brush. Simply sweep it towards the hood and dust & chips will be sucked up into the extractor.

  • Quiet Induction Motor
  • Highly Portable
  • 5 Micron Filter Bag
  • Tough Powder Coated Paint Finish
  • Transparent Collection Bag
  • Quick Action Metal Bag Clamps
  • Floor Sweep Attachment

The induction motor ensures that noise levels are kept to a minimum. Dust and chippings are all collected in the transparent collection bag which when full can either be emptied and refitted or disposed of and a replacement fitted.
The extractor is finished in a tough paint job to keep its looks for many years.
The maximum running time for this machine is 2 hours without rest. If you are a professional user who needs continuous extraction, please see the equivalent machine in our professional range W796.

Supplied with steel fan, 2 metre length of our tough adjustable length hose, transparent plastic collection bag with quick release metal strap, floor sweep attachment, castors, NVR switch, 2.1m cable and plug.

Please Note : Hose is Left Hand thread so for quick connector use 100QCL



Charnwood W696 Specification

Motor (Induction) 750w (1hp)
Voltage 240v
Flowrate (cubic metres per hour) 1020m3/hour
Inlet Diameter 100mm
Collection Bag Capacity 70 Litres
Dimensions (WxDxH) 900mm x 390mm x 1570mm
Weight 30kg
Assembly Time Required 45 Minutes
Rating Hobby
Product Guarantee 5 Years
We also have a large range of accessories available for connecting your dust extractor to the dust producing machinery. Reducers to join the 100mm diameter hose to the smaller diameter outlets usually found on bench top machinery. Hoods to collect dust from machinery with no purpose made collection points.
